SMT 2.00 Box Header Connector 2*15P PA9T UL94V-0 Line To Board Connector

Product Categories

WCON ELECTRONICS ( GUANGDONG) CO., LTD

Contact Now

SMT 2.00 Box Header Connector 2*15P PA9T UL94V-0 Line To Board Connector

Name: SMT 200 Box Header Connector 215P PA9T UL94V0 Line To Board Connector
Brand: WCON
Price: 1 USD

Wholesale SMT 2.00 Box Header Connector 2*15P PA9T UL94V-0 Line To Board Connector from china suppliers

Brand Name : WCON

Model Number : 3121-XXMG0BK00T1

Certification : UL/CUL/SGS/ROHS

Place of Origin : China

MOQ : 1000pcs

Price : Negotiation

Payment Terms : T/T

Supply Ability : 800000kpcs

Delivery Time : 15-25Day

Packaging Details : Tube Reel

Insulator Material : PA9T +30％GF( UL94V-0 )

Current Rating : 2.0AMP

Contact Resistance : 20mΩ Max

Withstand Voltage : 500V AC/DC

Contact Now

SMT 2.00 Box Header Connector 2*15P PA9T UL94V-0 Line to board connector

Current Rating	2.0AMP
Contact Resistance	20mΩ Max
Withstand Voltage	500V AC/DC
Insulation Resistance	1000mΩ Min
Operation Temperature	﹣40℃ to +105℃
Contact Material	Brass
Contact Plating	Au or Sn over Ni
Insulator Material	PA9T +30％GF( UL94V-0 )

Product name: Ejector

1. Product features: high temperature resistant to high voltage electrical conductivity

2. Product material: PA9T/LCP/PBT, plating surface treatment: gold-plated or tin plating

3. Scope of application: Mainly suitable for data communication and electronic equipment and welding on the PCB board, connected to the corresponding specification of IDC ribbon cable and the other circuit designers need to circuit. And if current usually transmission control signal

SMT 2.00 Box Header Connector 2*15P PA9T UL94V-0 Line To Board Connector

Drawing:Box Header 3121-XXMXXBK00XX(H=6.4).pdf

Product Tags:

board to wire connectors

male header connector

SMT 2.00 Box Header Connector 2*15P PA9T UL94V-0 Line To Board Connector Images
